SS Eye Wash With Shower

Technical Specification of SS Safety Shower with Eye Wash:

Pipe: SS 304 Bright Finish

Valve: Made from SS 304 Hot Forged. Through - Passage

Valve which opens automatically when the lever is pushed, and the valve stays open until it is manually closed.

Shower Head & Eyewash Bowl: In highly Visible Yellow ABS anti-corrosive plastic.

Spray Head Assembly: Two high flow Sprays aerated at low pressure which bathe the eyes and face of the injured person, with automatic anti-dust cover, which operate when the Eye wash is used and it is made of with Brass Pipe.

        Material of Construction: S.S. Pipe

        Inlet Connection: 1" B.S.P female thread.

        Outlet Connection: 1 1/2" B.S.P female thread.

        Color: Natural.

        Pressure Test: At 2.0 Kg/Cm2 in each Quantity.

        Easy to install.

        Minimum Discharge at 30PSI:

        For Eyewash = 1500 LPM

        For Shower = 3000 LPM
